NAT Traversal (NAT-T) Security Issues


Network Address Translation (NAT) is a technology that has, in a small way, revolutionized Internet communications. NAT allows multiple computers on a LAN to share a single public IP address for accessing the Internet. Without it, the IPv4 protocol’s limited number of available addresses would be pushed to its limits.

NAT also provides some measure of “cloaking” of internal computers, since they are “hidden” from external (Internet) computers that can only “see” the NAT device through which they connect.

NAT, however, has traditionally suffered from a big shortcoming. It’s incompatible with Internet Protocol Security (IPSec), which is an increasingly popular way to protect the confidentiality and integrity of data while it’s in transit over an IP network. The solution is NAT Traversal, or NAT-T. However, there are security problems related to NAT-T – or are there? Microsoft is recommending that IPSec/NAT-T not be used to connect a Windows XP client to Windows VPN servers that are behind NAT devices, and XP Service Pack 2 changes the default behavior to prevent IPSec/NAT-T security associations to servers behind a NAT. However, some security experts are saying this is overly cautious and the threat is more theoretical than real.

The problem with NAT and IPSec

Why doesn’t NAT work with IPSec? Remember that the point of IPSec is not just to protect the confidentiality of the data, but also to assure the authenticity of the sender and the integrity of the data (that it hasn’t been changed in transit). The problem with NAT is obvious: NAT must change information in the packet headers in order to do its job.

The first problem is that NAT changes the IP address of the internal computer to that of the NAT device. The Internet Key Exchange (IKE) protocol used by IPSec embeds the sending computer’s IP address in its payload, and this embedded address doesn’t match the source address of the IKE packet (which is that of the NAT device). When these addresses don’t match, the receiving computer will drop the packet.

Another problem is that TCP checksums (and optionally, UDP checksums) are used to verify the packets. The checksum is in the TCP header and it contains the IP addresses of the sending and receiving computers and the port numbers used for the communications.

With normal NAT communications, this isn’t a problem because the NAT device updates the headers to show its own IP address and port in place of the sending computer’s. However, IPSec encrypts the headers with the Encapsulating Security Payload (ESP) protocol. Since the header is encrypted, NAT can’t change it. This means the checksum is invalid, so the receiving computer rejects the packet.

In addition, NAT isn’t able to use the port numbers in TCP and UDP headers to multiplex packets to multiple internal computers when those headers have been encrypted by ESP.

NAT-T: How it works

The IPSec working group of the IETF has created standards for NAT-T that are defined in RFCs 3947 and 3948. NAT-T is designed to solve the problems inherent in using IPSec with NAT.

NAT-T adds a UDP header that encapsulates the ESP header (it sits between the ESP header and the outer IP header). This gives the NAT device a UDP header containing UDP ports that can be used for multiplexing IPSec data streams. NAT-T also puts the sending computer’s original IP address into a NAT-OA (Original Address) payload.

This gives the receiving computer access to that information so that the source and destination IP addresses and ports can be checked and the checksum validated. This also solves the problem of the embedded source IP address not matching the source address on the packet.

click below to read to the full post

Curated by Liquid Layer Networks

At Liquid Layer Web Hosting [], we’ve made a shared web hosting platform that’s both feature-rich and easy to make use of. Our programmers have built up a custom Linux cloud web hosting platform plus an innovative Control Panel that perfectly takes advantage of its capabilities. After long hours of programming and bug fixing on our end, we are now capable to guarantee that all of our shared web hosting services are safe, virus-free, full of capabilities and very easy-to-work-with. In addition, they feature 99.9% server uptime as well as 99.9% network uptime warranties.

Powered by:

HostCheetah Networks
Global Web Hosting, Domain Registration, and Internet Services |

PC Helper | Est 1996 - Web Hosting | US, AU, UK, Finland, Bulgaria | :sunglasses:



This is a very simplified account of how NAT-T makes it possible for IPSec and NAT to work together. For more detailed information, see RFC 3947 and RFC 3948.

IPSec/NAT-T Security Issues

IPSec is a security protocol. When you circumvent its normal behavior, for example by making the header information that it normally encrypts available, it makes sense that the level of security that it provides may be compromised.

Microsoft recently revealed that the way IPSec and NAT-T work can cause a security threat wherein IPSec traffic intended for one computer may be routed to the wrong computer, if certain criteria exist. For more details, see KB article 885348 .
